Wooden shelter elevation, section, proposed construction and chimney details dwg file
Description
Wooden shelter elevation, section, proposed construction and chimney details that includes a detailed view of isometric shelter elevation details, wood post and timber purline details, shelter floor plan details, chimney constructive structure details, foundation plan with pipe column footing and wall details, pit details and much more of shelter details.
