Thick side wall construction cad drawing details that includes a detailed view of layer- wall core polystyrene base material thickness of, layer-3 of wall of "to the base of concrete of thickness, concrete chain, rebar steel rod ", stirrup for chain frame ", Hollow for fastening and assembly. pvc base material, round "so" for post-tensioning, steel plate, see detail pl, reinforcement rod square cms, gate elevation details, sectional details, dimensions details, plan details, material details, footings details, design details, scale details, supportive wall details and much more of wall details.
