Overall floor framing plan and sanitary installation for office building dwg file


Description

Overall floor framing plan and sanitary installation for office building that includes a detailed view of wood posts with Grider pre-engineering, steel pipe column and play joints, existing floor joints, knee wall details provided with toilet plan details with toilet sectional details and passage, sanitary equipment installation details, doors and ventilation details with plumbing details and interior details with dimensions details, wall section details and much more of sanitary installation details.




File Type: DWG File ID: 83789
