Metal fascia and dam detail with membrane flashing and lap sealant detail dwg autocad drawing

Discover a comprehensive AutoCAD DWG drawing detailing the metal fascia and dam, complete with membrane flashing and lap sealant details, ideal for roofing projects. This detailed drawing offers insights into the installation of metal fascia and dams, along with the application of lap sealant and membrane flashing, ensuring water-tightness and durability. Additionally, it may include specifications for single-ply membrane roofing systems, rigid insulators, and treated wood blocks for secure attachment and insulation. Architects, roofers, and contractors can utilize this drawing to ensure precise installation and waterproofing of roofing systems. Accessible as a 2D AutoCAD drawing in DWG format, this file serves as a valuable resource for professionals involved in construction projects, facilitating seamless coordination and implementation of critical roofing details for optimal performance and longevity.
