2000x2000mm RC footing plan is given

Description

2000x2000mm RC footing plan is given in this AutoCAD drawing model. 10 numbers of bolts are used in this footing. Dimension details are given clearly in this drawing. For more details download the AutoCAD files for free from our website.

File Type:

DWG

Category::

Construction CAD Drawings, Blocks & 3D CAD Models

Sub Category::

Building Structure CAD Drawings, Blocks & 3D Design Models

type:

Free

Pavithra

View Profile
