House RCC Joint Beam Layout Plan AutoCAD Drawing


House RCC Joint Beam Layout Plan AutoCAD Drawing

Description

the typical joints of beams with columns (corner) column detail translators and joints for beams and lightened 1- do not join more than 50% of the area of the same section. 2- in case of not joining in the indicated areas or with the specified percentages, increase the joint length by 70%. download 2 storey house column beam layout plan CAD drawing DWG file. 3- for lightweight and chat beams, the lower steel will flange on the supports, being the length of joint equal to 25 cm. for 3/8 "and 35 cm iron. for 1/2" or 5/8 "
