Machinaries like transformer,LV panel,Generators and MV room floor plan and section details.Download DWG file.


Machinaries like transformer,LV panel,Generators and MV room floor plan and section details.Download DWG file.

Description

The drawing file contains the detailed explanation drawing of Machinery like a transformer, LV panel, Generators, and MV room floor plan and section. The land area of the M.V room is 77.42-meter square. The land area of the transformer room is 35.83-meter square.LV panel room land area is 44.82-meter square. And the generator room land area is 119.92-meter square. Download the DWG file.




File Type: DWG File ID: 160220
