Constructive details type of house with roof and foundation structure plan details dwg file


Constructive details type of house with roof and foundation structure plan details dwg file

Description

Constructive details type of house with roof and foundation plan details that includes a detailed view of Sheet metal roof with 15% slope, Corrugated sheets of galvanized iron n ° 24, Thermal insulation: expanded polystyrene 30mm esp. 20kg / , ³ dens. or lanan glass 35mm esp. and 18 kg / m³ density, Water-repellent aslation: 150 micron polyethylene film, Anchoring the wall to the wall with a sweet iron Ø 6, Pine truss elliotis in plain sight 1/2 "x4" brushed, Pine Elliotis brushed 2 "x 6", Sheet metal joinery according to plan, Hollow ceramic bricks 18x18x33 and much more of constructive details.




File Type: DWG File ID: 133341
