Beam structure details of joinery restaurant with false and lattice beams dwg file


Beam structure details of joinery restaurant with false and lattice beams dwg file

Description

Beam structure details of joinery restaurant with false and lattice beams that includes a detailed view of detail of lattice of false beams, detail of false beam for reticule, detail of false beam in bar, on wall, reinforce wall with wooden dogs, 1 "pine drum shelf with ocoume plywood: 9 mm, corrugated edges in ocumé, 1 "pine top drum door with 9mm ocumé plywood, cornered edges in ocumé and much more of structure details.




File Type: DWG File ID: 121547

Uploaded by:


profile Eiz Luna
New-Zealand
